The Maxxeon WorkStar 220 Pocket Floodlight lives up to its name with a broad, even swath of light with no hot spots.
About the size of a classic Bic “Stic” pen, the Pocket Floodlight puts out an amazing amount of light for its size.
The Pocket Floodlight has absolutely become our new favorite LED flashlight!
I must get at least a couple of dozen offers each week to try the new latest and greatest LED flashlight, each one promising the moon.
Most of them are ignored, but something about the name “Pocket Floodlight” triggered a “Hmmmm….sounds interesting” response and I took the bait.
I’m glad I did.
The Maxxeon Pocket Floodlight definitely lives up to its name and it provides a bright, broad, even beam of light with no hot spots.
The amount of light that this baby puts out is actually pretty incredible. I could qualify that by saying “for its size…”, but to be honest, it really is that bright.
In fact, it’s slightly brighter than the high-dollar Clearwater “Andie” flashlight (review) low setting.
And although the Andie’s high power setting naturally beats the Pocket Floodlight, there’s not as much difference as you’d think when the light patterns are viewed at realistic distances.
Besides the amazing amount of even light the Pocket Floodlight puts out, the best part about it is its size — it’s not much longer or thicker than the old classic Bic “Stic” pen.
And it even has a heavy-duty pocket clip so you can store it safely in your chest pocket.
If there’s room for a Bic pen on your motorcycle or toolbox, there’s room for a Pocket Floodlight.
The Maxxeon Pocket Floodlight – Details
The Pocket Floodlight is machined from 6061 T6 aluminum, the same stuff used in aerospace applications.
It weighs 44 grams (1.5 oz.) with its three AAAA Batteries and pocket clip installed and here’s a bonus: Maxxeon includes three high-quality Energizer batteries with the flashlight instead of those cheap no-name brands.
Maxxeon claims a battery life of up to 4 hours with intermittent use and all I can say is that two of us here have been using our Pocket Floodlights every day since we got them and the batteries are still going strong.
The business end holds a high-quality, 120 lumen Cree X-PE 3 Watt LED.
This is good stuff — Cree is one of the leading designers and manufacturers of modern LED light technology. The Cree X-PE LED is a new leading-edge design that is smaller than most of the LEDs in this range but puts out more light.
Cree offers the X-PE LED in a variety of light “temperatures” and Maxxeon chose the “Cool White” version for its clean, non-tinted color.
Cree rates it at 5,000 to 10,000 K and the light color has a very neutral tint, without the blue tint you usually see in LED lights like the Harbor Freight Gordon LED Flashlight (review) shown in the comparison photo below.
The Cree X-PE LED seems very close to 5,500 K to me, which is about the color of the sun around noon and is also the same color temperature as our daylight-balanced fluorescent studio lights.
This helps to bring out a more natural color to the subjects that are illuminated by the Pocket Floodlight — more so than most of the other LED flashlights I’ve used.
The Cree LED has a 115-degree light viewing angle, but as webBikeWorlders know, when you’re talking LEDs, it’s all about the reflector.
This is where the “Pocket Floodlight” name comes into its own. Maxxeon developed a special reflector that has an internal shape, texture and coating designed to eliminate hot spots.
The clever design also has a 1:1 ratio, so as you move the light 1 meter away from the workspace, the beam will be 1 meter wide. This makes the flashlight much more of a “floodlight” than other pencil-beamed LED flashlights.
The machined aluminum housing that holds the LED and the reflector has a series of vertical grip bars machined on the outside. The housing is threaded and it has an O-ring to make it water resistant.
In back of the LED housing is another machined cylinder that is threaded at both ends. This one features a beautiful cross-hatched knurling that provides a good grip for the user.
It screws on to the main body of the flashlight that holds the batteries and more O-rings seal the junctions.
The single tiny Cree X-PE LED in the Pocket Floodlight (L). Machined threads and O-rings (R).At the back end, the Pocket Floodlight features a thick rubber cover to protect the on/off switch.
The rubber has a nice molded-in crosshatch knurl. Maxxeon said that the rubber has been tested for over 100,000 on/off cycles, so this is pretty tough stuff.
The on/off switch assembly is located inside a machined aluminum section that screws on to the back of the Pocket Floodlight; it also has O-ring water protection. This housing also features the nicely knurled surface with a cross-hatch pattern to match the front.
The on/off switch is a two-way device. Press and hold the switch lightly to temporarily turn the light on or off or press it more firmly and the switch clicks and the light stays on.
The entire outside surface of the Pocket Floodlight has a black Type II anodized surface that provides corrosion resistance and durability.
All told, the features and specs mean that the Pocket Floodlight is a high-quality tool and not just another one of those two-buck el Cheapo LED flashlights. This is the real deal.
Pocket Floodlight Light Output Comparison
It’s difficult to illustrate the amount of light the Pocket Floodlight offers in either photos or videos, but here are some example shots, comparing it with some of the other LED flashlights I own and use quite often.
These are unretouched photos that were cropped to 650 pixels to fit the review.
The camera was set on a tripod 5 feet away from the motorcycle.
Each of these photos was taken at ISO 400, at 1/125 second shutter speed at f6.3, so the amount of light you see is comparable for each flashlight.
The lens is 20 mm wide, giving it a 35 mm SLR equivalent width of 35 mm on the APS-C sensor.
The white balance was set using a standardized 18% gray card, so the colors remain constant for each of these photos and you can see the differences.
BUY YOUR Maxxeon Pocket Floodlight and Maxxeon Flashlights Here!
The Clearwater Andie LED flashlight (review) costs about four times as much as the Pocket Floodlight, so this isn’t really a fair comparison but the Pocket Floodlight beats it at low beam. The Andie also uses a special rechargeable, custom-designed high-power battery and it’s an awesome flashlight, but it’s much larger and heavier than the Pocket Floodlight. What’s amazing here is that not only does the tiny Pocket Floodlight beat the low power beam of the Andie, it also doesn’t seem all that much different to the eye than the high beam of the Andie light.
Here’s the Clearwater Andie flashlight on high power. Again, not really a fair comparison because the Clearwater Andie costs $99.99 and uses its own special battery. Its high beam is a powerful light that packs a super photonic punch. But compare the spread to the much smaller, three AAAA battery Pocket Floodlight below, which will, of course, fit in your pocket! This is the 9-LED Harbor Freight Gordon LED (review), one of our previous favorites because it’s cheap and small. I was surprised at how little light it puts out compared to the Pocket Floodlight. The Gordon LED has a 9 LED array compared to the single Cree LED in the Pocket Floodlight. This illustrates how far LED technology has come since we began reviewing LED lights and flashlights nearly 10 years ago. Note also the blue tint from the Gordon LED.
The Princeton TEC Yukon headlamp (review) is also getting long in the tooth, but it keeps on going and the batteries seem to last forever. A headlamp is very useful when working on motorcycles, to be sure, but the Pocket Floodlight definitely surpasses both the Princeton low beam (above) and high beam (below). In addition, the Pocket Floodlight puts out a much broader and more useful light pattern and it has a whiter color tint than the Princeton.
The Princeton TEC LED headlamp on high beam puts out a narrow shaft of light.
The Pocket Floodlight definitely holds its own in this comparison and it puts out a broad, even swath of light.Conclusion
The Pocket Floodlight is a cool little LED flashlight that is very well made and puts out an amazing amount of light for its size (there, I said it!). Its size makes it really handy because it easily fits in your pocket, toolbox, tank bag or just about anywhere you can fit a Bic pen.
More wBW: Maxxeon WorkStar 320 Pocket Floodlight Review
BUY YOUR Maxxeon Pocket Floodlight and Maxxeon Flashlights Here!
| wBW Review: Maxxeon WorkStar 220 Pocket Floodlight | |
|---|---|
| Manufacturer: Maxxeon | List Price (2011): $31.00 |
| Colors: Black | Made In: China |
| Review Date: June 2011 | |
