2004 Shadow Aero 750
Engine |
|
| Engine Type | 745cc liquid-cooled 52-degree V-twin |
| Bore And Stroke | 79mm x 76mm |
| Compression Ratio | 9.6: 1 |
| Fuel System | Single 34.0mm CV type |
| Valve Train | SOHC; three valves per cylinder |
| Ignition | CD with electronic advance, two spark plugs per cylinder |
| Starting | |
DRIVETRAIN |
|
| Transmission | Wide-Ratio, 5-speed |
| Final Drive | Shaft |
CHASSIS / SUSPENSION / BRAKES |
|
| Front Suspension | 41.0mm fork; 4.6-inch travel |
| Rear Suspension | Dual shocks with five-position spring preload adjustability; 3.5-inch travel |
| Front Brakes | Single 296mm disc with twin-piston caliper |
| Rear Brake | 180.0mm Drum |
| Front Tire | 120/90-17 |
| Rear Tire | 160/80-15 |
DIMENSION |
|
| Rake | |
| Trail | |
| Wheelbase | 64.5 inches |
| Seat Height | 25.9 inches |
| Dry Weight | 519.4 pounds |
| Fuel Tank Capacity | 3.7 gallons, including 0.9-gallon reserve |
OTHER |
|
| Color |
|
| Emissions | California version differs slightly due to emissions equipment. |
| Model ID | VT750 |
| Warranty | 1 year |
2005 Shadow Aero 750
Engine |
|
| Engine Type | 745cc liquid-cooled 52-degree V-twin |
| Bore And Stroke | 79mm x 76mm |
| Compression Ratio | 9.6: 1 |
| Fuel System | Single 34.0mm CV type |
| Valve Train | SOHC; three valves per cylinder |
| Ignition | CD with electronic advance, two spark plugs per cylinder |
| Starting | |
DRIVETRAIN |
|
| Transmission | Wide-Ratio, 5-speed |
| Final Drive | Shaft |
CHASSIS / SUSPENSION / BRAKES |
|
| Front Suspension | 41.0mm fork; 4.6-inch travel |
| Rear Suspension | Dual shocks with five-position spring preload adjustability; 3.5-inch travel |
| Front Brakes | Single 296mm disc with twin-piston caliper |
| Rear Brake | 180.0mm Drum |
| Front Tire | 120/90-17 |
| Rear Tire | 160/80-15 |
DIMENSION |
|
| Rake | |
| Trail | |
| Wheelbase | 64.5 inches |
| Seat Height | 25.9 inches |
| Dry Weight | 519.4 pounds |
| Fuel Tank Capacity | 3.7 gallons, including 0.9-gallon reserve |
OTHER |
|
| Color |
|
| Emissions | California version differs slightly due to emissions equipment. |
| Model ID | VT750 |
| Warranty | 1 year |
2006 VT750 Shadow Aero
Engine |
|
| Engine Type | 745cc liquid-cooled 52-degree V-twin |
| Bore And Stroke | 79mm x 76mm |
| Compression Ratio | 9.6: 1 |
| Fuel System | Single 34.0mm CV type |
| Valve Train | SOHC; three valves per cylinder |
| Ignition | CD with electronic advance, two spark plugs per cylinder |
| Starting | |
DRIVETRAIN |
|
| Transmission | Wide-Ratio, 5-speed |
| Final Drive | Shaft |
CHASSIS / SUSPENSION / BRAKES |
|
| Front Suspension | 41.0mm fork; 4.6-inch travel |
| Rear Suspension | Dual shocks with five-position spring preload adjustability; 3.5-inch travel |
| Front Brakes | Single 296mm disc with twin-piston caliper |
| Rear Brake | 180.0mm Drum |
| Front Tire | 120/90-17 |
| Rear Tire | 160/80-15 |
DIMENSION |
|
| Rake | 34-degree |
| Trail | 161mm (6.3 inches) |
| Wheelbase | 64.5 inches |
| Seat Height | 25.9 inches |
| Dry Weight | 519.4 pounds |
| Fuel Tank Capacity | 3.7 gallons, including 0.9-gallon reserve |
OTHER |
|
| Color |
|
| Emissions | California version differs slightly due to emissions equipment. |
| Model ID | VT750 |
| Warranty |
2007 VT 750 Shadow Aero
OVERVIEW
- Overview: The only thing more stunning than this machine’s sweet retro styling accents is its unbelievable price tag. Long, low, powerful and covered in chrome from the fork covers to the rear brake pedal, with spoked wheels and classic valanced fenders, the 750cc V-twin Shadow Aero delivers full-size looks and muscle at a mid-size price.
Engine |
|
| Engine Type | 745cc liquid-cooled 52-degree V-twin |
| Bore And Stroke | 79mm x 76mm |
| Compression Ratio | 9.6: 1 |
| Fuel System | Single 34.0mm CV type |
| Valve Train | SOHC; three valves per cylinder |
| Ignition | CD with electronic advance, two spark plugs per cylinder |
| Starting | |
DRIVETRAIN |
|
| Transmission | Wide-Ratio, 5-speed |
| Final Drive | Shaft |
CHASSIS / SUSPENSION / BRAKES |
|
| Front Suspension | 41.0mm fork; 4.6-inch travel |
| Rear Suspension | Dual shocks with five-position spring preload adjustability; 3.5-inch travel |
| Front Brakes | Single 296mm disc with twin-piston caliper |
| Rear Brake | 180.0mm Drum |
| Front Tire | 120/90-17 |
| Rear Tire | 160/80-15 |
DIMENSION |
|
| Rake | 34-degree |
| Trail | 161mm (6.3 inches) |
| Wheelbase | 64.5 inches |
| Seat Height | 25.9 inches |
| Dry Weight | 519.4 pounds |
| Fuel Tank Capacity | 3.7 gallons, including 0.9-gallon reserve |
OTHER |
|
| Color |
|
| Emissions | California version differs slightly due to emissions equipment. |
| Model ID | VT750 |
| Warranty |
2008 VT 750 Shadow Aero
Overview:
- Full-sized looks and 750cc performance without the full-sized price tag. Sound like a stretch? Not when you’re talking about the Honda Shadow Aero. Stunning is one way to describe its long, low, retro styling simply drenched in chrome from tip to tail and boasting classic valanced fenders, spoked wheels and five all-new colors. Staggering is another — especially once you see that all this muscular V-twin style and performance could be yours for a mid-sized price.
Engine |
|
| Engine Type | 745cc liquid-cooled 52-degree V-twin |
| Bore And Stroke | 79mm x 76mm |
| Compression Ratio | 9.6: 1 |
| Fuel System | Single 34.0mm CV type |
| Valve Train | SOHC; three valves per cylinder |
| Ignition | CD with electronic advance, two spark plugs per cylinder |
| Starting | |
DRIVETRAIN |
|
| Transmission | Wide-Ratio, 5-speed |
| Final Drive | Shaft |
CHASSIS / SUSPENSION / BRAKES |
|
| Front Suspension | 41.0mm fork; 4.6-inch travel |
| Rear Suspension | Dual shocks with five-position spring preload adjustability; 3.5-inch travel |
| Front Brakes | Single 296mm disc with twin-piston caliper |
| Rear Brake | 180.0mm Drum |
| Front Tire | 120/90-17 |
| Rear Tire | 160/80-15 |
DIMENSION |
|
| Rake | 34-degree |
| Trail | 161mm (6.3 inches) |
| Wheelbase | 64.5 inches |
| Seat Height | 25.9 inches |
| Curb Weight | N/A |
| Fuel Tank Capacity | 3.7 gallons, including 0.9-gallon reserve |
OTHER |
|
| Color |
|
| Emissions | California version differs slightly due to emissions equipment. |
| Model ID | VT750 |
| Warranty | 1 year Warranty Coverage of defects in materials and workmanship |
2009 VT 750 Shadow Aero
Engine |
|
| Engine Type | 745cc liquid-cooled 52-degree V-twin |
| Bore And Stroke | 79mm x 76mm |
| Compression Ratio | 9.6: 1 |
| Fuel System | Single 34.0mm CV type |
| Valve Train | |
| Ignition | CD with electronic advance, two spark plugs per cylinder |
| Starting | |
DRIVETRAIN |
|
| Transmission | Wide-Ratio, 5-speed |
| Final Drive | Shaft |
CHASSIS / SUSPENSION / BRAKES |
|
| Front Suspension | 41.0mm fork; 4.6-inch travel |
| Rear Suspension | Dual shocks with five-position spring preload adjustability; 3.5-inch travel |
| Front Brakes | Single 296mm disc with twin-piston caliper |
| Rear Brake | 180.0mm Drum |
| Front Tire | 120/90-17 |
| Rear Tire | 160/80-15 |
DIMENSION |
|
| Rake | |
| Trail | |
| Wheelbase | 64.5 inches |
| Seat Height | 25.9 inches |
| Curb Weight | 553 lbs. |
| Fuel Tank Capacity | 3.7 gallons |
OTHER |
|
| Color | Metallic Titanium/White, Pearl Blue/Metallic Silver, Black/Snakeskin Pattern, Candy Dark Red, Black |
| Price | $6999 |
| Model ID | VT750 |
| Warranty | 1 year |
2010 VT750A Shadow Aero
Engine |
|
| Engine Type | 745cc liquid-cooled 52-degree V-twin |
| Bore And Stroke | 79mm x 76mm |
| Compression Ratio | 9.6: 1 |
| Fuel System | PGM-FI electronic fuel injection |
| Valve Train | Chain-driven SOHC, 3 valves per cylinder |
| Ignition | |
| Starting | |
DRIVETRAIN |
|
| Transmission | Wide-Ratio, 5-speed |
| Final Drive | Shaft |
CHASSIS / SUSPENSION / BRAKES |
|
| Front Suspension | 41 mm fork, 117 mm (4.6 in.) travel |
| Rear Suspension | Dual shocks with adjustable spring preload; 89 mm (3.5 in.) travel |
| Front Brakes | Front single 296 mm disc with dual-piston caliper |
| Rear Brake | single 276 mm disc with single-piston caliper. Combined |
| Front Tire | 120/90-17 |
| Rear Tire | 160/80-15 |
DIMENSION |
|
| Rake | |
| Trail | |
| Wheelbase | 1,640 mm (64.6 in.) |
| Seat Height | 658 mm (25.9 in.) |
| Curb Weight | 262 kg (578 lb) including required fluids and full tank of gas – ready to ride |
| Fuel Tank Capacity | 14.6 litres, including 3.5-litre reserve |
OTHER |
|
| Color | Heavy Grey Metallic/Candy Blaze Orange |
| Price | $9,799 (ASB) |
| Model ID | |
| Warranty | 1 year, unlimited mileage, freely transferable warranty, extended coverage available with Honda Plus |
2011 VT750A Shadow Aero
Engine |
|
| Engine Type | 745cc liquid-cooled 52-degree V-twin |
| Bore And Stroke | 79mm x 76mm |
| Compression Ratio | 9.6: 1 |
| Fuel System | PGM-FI with automatic enrichment circuit, 34mm throttle body |
| Valve Train | Chain-driven SOHC, 3 valves per cylinder |
| Ignition | Digital transistorized with electronic advance |
| Starting | |
DRIVETRAIN |
|
| Transmission | Wide-Ratio, 5-speed |
| Final Drive | Shaft |
CHASSIS / SUSPENSION / BRAKES |
|
| Front Suspension | 41 mm fork; 117 mm (4.6 in.) travel |
| Rear Suspension | Dual shocks with spring preload adjustment; 89 mm (3.5 in.) travel |
| Front Brakes | Front Brakes (ABS): Single 296 mm disc with triple-piston caliper, Combined Braking System with ABS; Front Brake (non-ABS): Single 296mm disc with twin-piston caliper |
| Rear Brake | Rear Brakes (ABS): 276 mm disc with single-piston caliper. Combined Braking System with ABS; Rear Brake (non-ABS): 180mm drum |
| Front Tire | 120/90-17 |
| Rear Tire | 160/80-15 |
DIMENSION |
|
| Rake | 34.0 degree (Caster Angle) |
| Trail | 161mm (6.3 inches) |
| Wheelbase | 1,640 mm (64.6 in.) |
| Seat Height | 660 mm (26 in.) |
| Curb Weight | (non-ABS): 251 kg (553 lb); ABS): 262 kg (578 lb) |
| Fuel Tank Capacity | 14 litres (3.7 GalUS), including 3.5-litre (0.9 Gal) reserve |
OTHER |
|
| Color | Candy Red |
| Price | $9,999 |
| Model ID | VT750C |
| Warranty | 1 year, unlimited mileage, freely transferable warranty, extended coverage available with Honda Plus |
| Emissions | Meets current EPA standards. California version meets current CARB standards and may differ slightly due to emissions equipment. |
| Fuel consumption | 4.2 L/100km (56 mpgUS) |
2012 VT750CA Shadow Aero
Engine |
|
| Engine Type | 745cc liquid-cooled 52-degree V-twin |
| Bore And Stroke | 79mm x 76mm |
| Compression Ratio | 9.6: 1 |
| Fuel System | PGM-FI with automatic enrichment circuit, 34mm throttle body |
| Valve Train | Chain-driven SOHC, 3 valves per cylinder |
| Ignition | Digital transistorized with electronic advance |
| Starting | |
DRIVETRAIN |
|
| Transmission | Wide-Ratio, 5-speed |
| Final Drive | Shaft |
CHASSIS / SUSPENSION / BRAKES |
|
| Front Suspension | 41 mm fork; 117 mm (4.6 in.) travel |
| Rear Suspension | Dual shocks with spring preload adjustment; 89 mm (3.5 in.) travel |
| Front Brakes | ABS Brakes: Front single 296 mm disc with triple-piston caliper; Non-ABS Front Brake: Single 296mm disc with twin-piston caliper |
| Rear Brake | Single 276 mm disc with single-piston caliper, ABS Brakes: Combined Braking System with ABS (Anti-lock Braking System); Non-ABS Rear Brake: 180mm drum |
| Front Tire | 120/90-17 |
| Rear Tire | 160/80-15 |
DIMENSION |
|
| Rake | 34.0 degree (Caster Angle) |
| Trail | 161mm (6.3 inches) |
| Wheelbase | 1,640 mm (64.6 in.) |
| Seat Height | 660 mm (26 in.) |
| Curb Weight | ABS Curb Weight: 262 kg (578 lb), Non-ABS Curb Weight: 254 kg (560 lb) |
| Fuel Tank Capacity | 14 litres (3.7 GalUS), including 3.4 litre (0.9 GalUS) reserve |
OTHER |
|
| Color |
|
| Price | $9,499 |
| Model ID | Non-ABS Model Id: VT750C, ABS Model Id: VT750CA |
| Warranty | 1 year, unlimited mileage, freely transferable warranty; extended coverage available with Honda Plus |
| Emissions | Meets current EPA standards. California version meets current CARB standards and may differ slightly due to emissions equipment. |
| Fuel consumption | 4.2 L/100km (56 mpgUS) |
