Engine
|
|
| Engine Type |
Air-cooled 4-stroke OHC 2v single |
| Displacement |
49cc |
| Bore and Stroke |
37.8 x 44mm |
| Compression Ratio |
10:1 |
| Fuel Delivery |
PGM-FI electronic fuel injection |
| Ignition |
Full-transistor battery ignition |
| Max. Torque |
3.5Nm/6,750min-1 (95/1/EC) |
| Max. Power Output |
2.5kW/7,000min-1 (95/1/EC) |
DRIVETRAIN
|
|
| Transmission |
Continuously variable (V-Matic) |
| Final Drive |
V-Belt |
| Front Wheels |
Cast aluminium MT1.85 |
| Rear Wheels |
Cast aluminium MT1.85 |
CHASSIS / SUSPENSION / BRAKES
|
|
| Front Suspension |
Telescopic forks with hydraulic damping |
| Rear Suspension |
Unit swingarm |
| Front Brakes |
220mm hydraulic disc |
| Rear Brakes |
130mm drum |
| Front Tire |
80/90 |
| Rear Tire |
90/90 |
DIMENSION
|
|
| Rake |
27.03 degrees |
| Trail |
61.5mm (2.4 inches) |
| Wheelbase |
1284mm (50.5 inches) |
| verall Length |
1882mm (74 inches) |
| Overall Width |
670mm (26.4 inches) |
| Overall Height |
1117mm (44 inches) |
| Seat Height |
785mm (30.9 inches) |
| Ground Clearance |
144mm (5.7 inches) |
| Weight |
100 kg (220 lb)
- Front: 40 kg (88 lb)
- Rear: 60 kg (132 lb)
|
| Fuel Capacity |
5.5 Litres (1.45 GalUS) |
OTHER
|
|
| Fuel Consumption |
1.9 L/100km (122.3 mpgUS) (32.3 miles/litre) (146.9 mpg-imp) |
