Engine
|
|
| Engine Type |
Air cooled 4-stroke OHC 2v single |
| Displacement |
108cc |
| Bore and Stroke |
50 x 55mm |
| Compression Ratio |
9.5:1 |
| Fuel Delivery |
PGM-FI programmed fuel injection system |
| Ignition |
Full-transistor battery ignition |
| Max. Power Output |
6.2kW / 8000min-1 (95/1/EC) |
| Max. Torque |
8.7Nm / 6500min-1 (95/1/EC) |
| Starter |
Electric |
DRIVETRAIN
|
|
| Transmission |
V-Matic |
| Final Drive |
V-belt |
| Front Wheel |
5-spoke cast aluminium |
| Rear Wheel |
5-spoke cast aluminium |
CHASSIS / SUSPENSION / BRAKES
|
|
| Front Suspension |
Telescopic forks with hydraulic damping |
| Rear Suspension |
Unit swingarm |
| Front Brakes |
220mm disc (with Combined Brake System) |
| Rear Brakes |
130mm drum (with Combined Brake System) |
| Front Tire |
80/90 14 |
| Rear Tire |
90/90 14 |
DIMENSION
|
|
| Seat Height |
755mm (29.7 inches) |
| Wheelbase |
1255mm (49.4 inches) |
| Curb Weight |
102 kg (224.4 lb) |
| Fuel Capacity |
5.5 Litres (1.45 GalUS) |
| Ground Clearance |
120mm (4.7 inches) |
| Overall Length |
1845mm (72.6 inches) |
| Overall Width |
670mm (26.4 inches) |
| Overall Height |
1090 mm (42.9 inches) |
| Front |
41 kg (90.2 lb) |
| Rear |
61 kg (134.2 lb) |
