Engine
|
|
| Engine Type |
Liquid-cooled,turbo-charged, transverse V-Twin |
| Bore and Stroke |
82.5mm x 63mm |
| Valves |
Chain driven SOHC, 4 valves per cylinder |
| Displacement |
670cc |
| Compression Ratio |
7.8:1 |
| Fuel Delivery |
Computerized fuel injection |
| Ignition System |
High-energy transistorized |
| Fuel type |
Regular gasoline |
| Starter |
Electric |
DRIVETRAIN
|
|
| Transmission |
Five-speed constant mesh |
| Final Drive |
Shaft |
| Clutch |
Wet, multi-plate |
| Wheels |
ComStarTM |
CHASSIS / SUSPENSION / BRAKES
|
|
| Front Suspension |
Air-assisted telescopic with TRACTM anti-dive |
| Rear Suspension |
Pro-LinkTM air-assisted single shock |
| Front Tire |
100/90V18 |
| Rear Tire |
120/90V17 |
| Front Brakes |
Dual discs, Double piston calipers |
| Rear Brakes |
Single disc, Double piston calipers |
DIMENSION
|
|
| Wheelbase |
1495mm (58.9 in.) |
| Seat height |
790mm (31.1 in.) |
| Fuel capacity |
20 liters (5.3 GalUS) |
| Dry weight: |
235 kg (518 lb) |
| Overall length |
2220mm (87.4 in.) |
| Overall width |
775mm (30.5 in.) |
OTHER
|
|
| Color |
Pearl Shell White with Candy Aleutian Blue. |
