Engine
|
|
| Engine Type |
153cc liquid-cooled single-cylinder four-stroke |
| Bore and Stroke |
58mm x 57.8mm |
| Compression Ratio |
11.0:1 |
| Valve Train |
SOHC; two-valve |
| Fuel Delivery |
Programmed Fuel Injection (PGM-FI) with automatic enricher circuit |
| Ignition |
Digital transistorized with electronic advance |
DRIVETRAIN
|
|
| Transmission |
Honda V-Matic belt-converter automatic transmission |
CHASSIS / SUSPENSION / BRAKES
|
|
| Front Suspension |
33mm hydraulic fork; 3.5 inches travel |
| Rear Suspension |
Swingarm with dual hydraulic shocks, spring-preload adjustability; 3.3 inches travel |
| Front Brakes |
Single 220mm disc with a two piston caliper (CBS) |
| Rear Brakes |
Drum (CBS) 130mm |
| Front Tire |
100/80-16 |
| Rear Tire |
120/80-16 |
DIMENSION
|
|
| Seat Height |
30.9 inches |
| Wheelbase |
53.4 inches |
| Curb Weight |
162 kg (357 lb) |
| Fuel Capacity |
1.8 gallons, including 0.5-gallon reserve |
| Miles Per Gallon |
91 MPG – Honda’s fuel economy estimates are based on EPA exhaust emission measurement test procedures and are intended for comparison purposes only. Your actual mileage will vary depending on how you ride, how you maintain your vehicle, weather, road conditions, tire pressure, installation of accessories, cargo, rider and passenger weight, and other factors. |
OTHER
|
|
| Emissions |
Meets current California Air Resources Board (CARB) and EPA standards. |
| Available Colors |
Metallic Red, Metallic Black |
| Model Id |
SH150i |
| FACTORY WARRANTY INFORMATION |
One Year: Transferable, unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan. |
