Engine
|
|
| Engine Type |
Liquid-cooled 4-stroke SOHC single |
| Displacement |
125cc |
| Bore and Stroke |
52.4 x 57.8mm |
| Compression Ratio |
11:1 |
| Carburation |
PGM-FI electronic fuel injection |
| Ignition |
Digital transistorised with electronic advanced |
| Max. Power Output |
10.1kW/9,000min-1 (95/1/EC) |
| Max. Torque |
11.5Nm/7,000min-1 (95/1/EC) |
| Starter |
Electric |
DRIVETRAIN
|
|
| Transmission |
V-Matic |
| Final Drive |
Belt drive |
| Front Wheel |
U-section 6-spoke cast aluminium |
| Rear Wheel |
U-section 6-spoke cast aluminium33mm telescopic fork, 89mm axle travel |
CHASSIS / SUSPENSION / BRAKES
|
|
| Front Suspension |
33mm telescopic fork, 89mm axle travel |
| Rear Suspension |
Dual-damper unit swingarm, 83 mm axle travel |
| Front Brakes |
220 x 4 mm hydraulic disc with dual-piston caliper and sintered metal pads |
| Rear Brakes |
130 mm leading/trailing drum130 mm leading/trailing drum |
| Front Tire |
110/90-13M/C 56L |
| Rear Tire |
130/70-13M/C 57L |
DIMENSION
|
|
| Seat Height |
800mm (31.5 inches) |
| Wheelbase |
1340mm (52.8 inches) |
| Curb Weight |
135 kg (297 lb) |
| Fuel Capacity |
8 Litres (2.1 GalUS) |
| Ground Clearance |
125mm (4.9 inches) |
| Overall Length |
1990mm (78.3 inches) |
| Overall Width |
700mm (27.6 inches) |
| Overall Height |
1150mm (45.3 inches) |
| Front |
54 kg (119 lb) |
| Rear |
81 kg (178 lb) |
