Engine
|
|
| Engine Type |
4-stroke 2-valve SOHC with built-in liquid cooling |
| Displacement |
124.9cc |
| Bore and Stroke |
52.4 x 57.9mm |
| Compression Ratio |
11:1 |
| Fuel Delivery |
PGM-FI electronic fuel injection |
| Carburation |
PGM-FI electronic fuel injection |
| Ignition |
Fully transistorised electric |
| Max. Power Output |
8.33kW/8,000min-1 (95/1/EC) |
| Max. Torque |
11.56Nm/6,000min-1 (95/1/EC) |
| Starter |
Electric |
DRIVETRAIN
|
|
| Transmission |
V-Matic – Centrifugal Automatic |
| Final Drive |
Belt drive |
| Front Wheel |
5-spoke cast aluminium 14M/C x MT1.85 |
| Rear Wheel |
5-spoke cast aluminium 14M/C x MT2.15 |
CHASSIS / SUSPENSION / BRAKES
|
|
| Front Suspension |
31mm telescopic fork, 100mm stroke |
| Rear Suspension |
Twin suspension aluminium swingarm, 75mm stroke |
| Front Brakes |
220mm hydraulic disc with Combined 3-piston caliper |
| Rear Brakes |
130mm Combined leading/trailing drum |
| Front Tire |
90/90-14M/C (46P) |
| Rear Tire |
100/90-14M/C (57P) |
DIMENSION
|
|
| Overall Length |
1917mm (75.5 inches) |
| Overall Width |
738mm (28.9 inches) |
| Overall Height |
1094mm (43.1 inches) |
| Front |
52.2 kg (115 lb) |
| Rear |
72.2 kg (159 lb) |
| Seat Height |
761mm (30 inches) |
| Wheelbase |
1305mm (51.4 inches) |
| Curb Weight |
124.4 kg (274 lb) |
| Fuel Capacity |
6.2 Litres (1.6 GalUS) |
| Ground Clearance |
135mm (5.3 inches) |
