Engine
|
|
| Engine Type |
Liquid-cooled 4-stroke 8-valve, SOHC parallel 2-cylinder |
| Bore and Stroke |
73 x 80mm |
| Valves |
Chain driven SOHC, 4 valves per cylinder |
| Displacement |
670cc |
| Compression Ratio |
10.7:1 |
| Fuel Delivery |
PGM-FI electronic fuel injection, 36mm throttle body |
| Ignition System |
Computer-controlled digital transistorised with electronic advance |
| Throttle Bore |
36mm |
| Starter |
Electric |
| Max. Torque |
60Nm/4,750min-1 (95/1/EC) |
| Max. Power Outpu |
35kW/6,250min-1 – 95/1/EC (DCT version = 38.1kW/6,250min-1) |
DRIVETRAIN
|
|
| Transmission |
6-speed, |
| Final Drive |
O-ring sealed chain |
| Clutch |
Wet multiplate (DCT version =Wet multiplate, hydraulic 2-clutch) |
| Clutch Operation |
Manual (DCT version = D mode/S mode/Manual mode) |
| Front Wheels |
- (Multi-spoke cast aluminium 17M/C x MT3.5
|
| Rear Wheels |
- (Multi-spoke cast aluminium 17M/C x MT4.5
|
CHASSIS / SUSPENSION / BRAKES
|
|
| Frame type |
Diamond; steel pipe |
| Front Suspension |
41mm telescopic fork, 153.5mm (6 in.) travel |
| Rear Suspension |
Monoshock damper, Pro-Link® swingarm, 150mm (5.9 in.) travel |
| Front Tire |
120/70-ZR17M/C (58W) |
| Rear Tire |
160/60-ZR17M/C (69W) |
| Front Brakes |
320mm single wave/wavy hydraulic disc with 2-piston caliper and sintered metal pads |
| Rear Brakes |
40 single wave/wavy hydraulic disc with single-piston caliper and sintered metal pads |
DIMENSION
|
|
| Rake/trail |
27.0 degrees/110.0mm (4.3 inches) |
| Wheelbase |
1540mm (60.6 inches) |
| Overall Length |
2210mm (87 inches) |
| Overall Width |
830mm (32.7 inches) |
| Overall Height |
1285mm (50.6 inches) |
| Curb Weight |
218kg (480 lb) |
| Seat Height |
830mm (32.7 inches |
| Ground Clearance |
165mm (6.5 inches) |
| Fuel Tank Capacity |
14.1 Litres (3.7 Gal US) |
OTHER
|
|
| Color |
-
- Darkness Black Metallic
- Light Silver Metallic
|
| Fuel Consumption |
3.6 L/100km (78.2mpg Imp.) (65.1 mpg US) |
| Warranty |
1 year, unlimited mileage, freely transferable warranty; extended coverage available with Honda Plus |
| Model Id |
NC700X |
| Emissions |
Meets current EPA standards. Models sold in California meet current CARB standards and may differ slightly due to emissions equipment. |
