| Engine Type |
Air-cooled, 4-stroke single |
| Bore and Stroke |
100 x 82mm |
| Displacement |
644cc |
| Compression Ratio |
8.3:1 |
| Carburation |
40 mm VE-type carburetor |
| Max. Power Output |
37 bhp at 5,750 rpm |
| Max. Torque |
52.3 Nm at 4,500 rpm |
| Ignition |
Fully transistorised electronic |
| Starter |
Electric |
| Gearbox |
5-Speed |
| Final Drive |
O-ring sealed chain |
| Length x Width x Height |
2,151 x 823 x 1,157 mm |
| Wheelbase |
1,490 mm |
| Seat Height |
875 mm |
| Ground Clearance |
216 mm |
| Fuel Capacity |
Fuel Capacity |
| Dry Weight |
163 kg |
| Wheels Front |
17M/C x MT3.50 aluminum rim/steel spoke |
| Wheels Rear |
17M/C x MT4.00 aluminum rim/steel spoke |
| Tires Front |
120/70 R17M/C 58H |
| ires Rear |
150/60 R17M/C 66H |
| Suspension Front |
45mm inverted leading-axle telescopic fork,218mm axle travel |
| Suspension Rear |
Pro-Link, 186mm axle travel |
| Brakes Front |
296 x 4mm hydraulic disc with dual-pistoncaliper and sintered metal pads |
| Brakes Rear |
220 x 5mm hydraulic disc with single-piston caliper and sintered metal pads |
