Engine
|
|
| Engine Type |
4-Stroke, Single Cylinder, Air Cooled |
| Displacement |
147.7 cc |
| Max. Power |
6.0 KW (8.2 bhp) @ 6000 rpm |
| Max. Torque |
10.63 Nm @ 4000 rpm |
| Starting |
Kick |
| System Voltage |
12V |
DRIVETRAIN
|
|
| Transmission |
4 Speed Constant Mesh |
| Clutch |
Wet Multiplate |
CHASSIS / SUSPENSION / BRAKES
|
|
| Frame |
High Rigidity Under Bone |
| Front Suspension |
Bottom Link, Spring Loaded Hydraulic Damper |
| Rear Suspension |
Unit Swing, Spring Loaded Hydraulic Damper |
| Front Brakes |
Drum, 130 mm DIA |
| Rear Brakes |
Drum, 130 mm DIA |
| Front Tire |
3.50 – 10, 4PR |
| Rear Tire |
3.50 – 10, 4PR |
DIMENSION
|
|
| Overall length |
1810mm |
| Width |
Width |
| Height |
1132mm |
| Wheelbase |
1247 mm |
| Ground Clearance |
161 mm |
| Fuel Tank Capacity |
4.5 litres |
OTHER
|
|
| Headlamp |
35/35 W |
