Engine
|
|
| Engine Type |
108cc liquid-cooled single-cylinder four-stroke |
| Valve Train |
SOHC; two-valve |
| Bore and Stroke |
50mm x 55mm |
| Compression Ratio |
11.0:1 |
| Fuel Delivery |
Programmed Fuel Injection (PGM-FI) with automatic enrichment |
| Ignition |
Digital transistorized with electronic advance |
| Starter |
Electric |
DRIVETRAIN
|
|
| Transmission |
Honda V-Matic belt-converter automatic transmission |
CHASSIS / SUSPENSION / BRAKES
|
|
| Front Suspension |
33mm hydraulic fork; 3.1 inches travel |
| Rear Suspension |
Swingarm with single hydraulic shock; 2.8 inches travel |
| Front Brakes |
Single 190mm disc with CBS two piston caliper |
| Rear Brakes |
130mm drum with CBS |
| Front Tire |
90/90-12 |
| Rear Tire |
100/90-10 |
DIMENSION
|
|
| Miles Per Gallon |
107 MPG* |
| Seat Height |
29.1 inches |
| Wheelbase |
50.2 inches |
| Curb Weight |
254 pounds (Includes all standard equipment, required fluids and a full tank of fuel ready to ride) |
| Fuel Capacity |
1.6 gallons |
| Ground Clearance |
173mm |
| Rake |
(Caster Angle): 26.5 degrees |
| Trail |
74mm (2.9 inches) |
OTHER
|
|
| Emissions |
Meets current EPA standards. |
| Available Colors |
Red, Black |
| Model Id |
NHX110 |
| FACTORY WARRANTY INFORMATION |
One Year: Transferable, unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan. |
