Engine
|
|
| Engine Type |
Liquid-cooled 4-stroke 16-valve DOHC 90° V-4 |
| Displacement |
782cc |
| Bore and Stroke |
72 X 48mm |
| Compression Ratio |
11.6:1 |
| Spark Plug Type |
IMR9D-9H (NGK); VNH27Z (DENSO) |
| Fuel Delivery |
PGM-FI electronic fuel injection |
| Throttle Bore |
36mm |
| Idling Speed |
1200min-1 |
| Ignition System |
Computer-controlled digital transistorised with electronic advance |
| Ignition Timing |
8° BTDC (idle) ~ 50° BTDC (1200min-1) |
| Battery Capacity |
12V/11AH (YTZ-12S) |
| Starter |
Electric |
| Max. Torque |
72.8Nm/9,500min-1 (95/1/EC) |
| Max. Power Output |
74.9kW/10,000min-1 (95/1/EC) |
| ACG Output |
386W |
DRIVETRAIN
|
|
| Transmission Type |
Constant mesh 6-speed |
| Primary Reduction: |
1.934 (64/33) |
| Final Reduction |
2.687 (43/16) |
| Final Drive |
O-ring sealed chain |
| Clutch |
Wet, multiplate with coil springs |
| Clutch Operation |
Hydraulic |
CHASSIS / SUSPENSION / BRAKES
|
|
| Frame type |
Diamond; aluminium twin-spar; pivotless |
| Caster Angle |
25° 45′ |
DIMENSION
|
|
| Fuel Tank Capacity |
21.5 Litres (5.7 Gal |
| Air Cleaner |
Oil-permeated, cartridge-type paper filter |
| Wheelbase |
1,464mm (57.6 inches) |
| Overall Length |
2130mm (83.9 inches) |
| Overall Width |
799mm (34.5 inches) |
| Overall Height |
1243mm (48.9 inches) |
| Trail |
96mm |
