Engine
|
|
| Engine Type |
23cc air-cooled single-cylinder four-stroke |
| Displacement |
9.0:1 |
| Bore and Stroke |
65.5 x 66.2 mm |
| Compression Ratio |
10.7:1 |
| Valve Train |
SOHC; two valve |
| Fuel Delivery |
30mm CV carburetor |
| Ignition |
CD |
DRIVETRAIN
|
|
| Transmission |
6-speed |
| Final Drive |
#520 O-ring-sealed chain; 13T/38T |
CHASSIS / SUSPENSION / BRAKES
|
|
| Front Suspension |
37mm leading-axle Showa fork; 9.0 inches of travel |
| Rear Suspension |
Pro-Link Showa single shock with spring preload adjustability; 6.6 inches of travel |
| Front Brakes |
Single 240 mm disc |
| Rear Brakes |
220 mm disc |
| Front Tire |
110/70-17 Dunlop GT401 Arrowmax |
| Rear Tire |
130/70 Dunlop GT401 Arrowmax |
DIMENSION
|
|
| Seat Height |
31.7 inches |
| Wheelbase |
52.6 inches |
| Curb Weight |
276 lbs (*Includes all standard equipment, required fluids and full tank of fuel-ready to ride) |
| Fuel Capacity |
2.3 gallons, including 0.7 gallon reserve |
| Rake |
(Caster Angle): 23.9 degrees |
| Trail |
3.58 inches (91mm) |
| iles Per Gallon |
83 MPG – Honda’s fuel economy estimates are based on EPA exhaust emission measurement test procedures and are intended for comparison purposes only. Your actual mileage will vary depending on how you ride, how you maintain your vehicle, weather, road conditions, tire pressure, installation of accessories, cargo, rider and passenger weight, and other factors. |
OTHER
|
|
| Available Colors |
Black |
| Warranty |
1 year, unlimited mileage, freely transferable warranty, extended coverage available with Honda Plus |
| Fuel consumption |
Meets current CARB and EPA standards |
| Emissions |
Meets current EPA standards. Models sold in California meet current CARB standards and may differ slightly due to emissions equipment. |
| FACTORY WARRANTY INFORMATION |
One Year: Coverage of defects in materials and workmanship |
