Engine
|
|
| Engine |
air cooled single cylinder 4 cycles |
| Displacement |
49cc |
| Bore & Stroke |
39.0mm × 41.4mm |
| Compression ratio |
10.0:1 |
| Carburetor |
VC 58 |
| Starting system |
Kick system |
| Ignition device type |
CDI type magnetic ignition |
| Lubricating system |
Force splash combined use system |
DRIVETRAIN
|
|
| Clutch type |
Wet multiple plate coil spring system |
| Transmission type |
Regular gearing three speed |
| 1st gear ratio |
3.272:1 |
| 2nd gear ratio |
1.823:1 |
| 3rd gear ratio |
1.190:1 |
CHASSIS / SUSPENSION / BRAKES
|
|
| Tire size |
3.50-10-2 PR (front and rear) |
| Brake type |
Mechanical cable type leading & trailing (front & rear) |
| Front suspension |
Telescopic system |
| Rear suspension |
Swing arm |
| Frame type |
Low floor backbone |
DIMENSION
|
|
| length |
1665 mm (65.5″) |
| width |
645 mm (25″) |
| height |
985 mm (39″) |
| Wheelbase |
1100 mm (43″) |
| Road clearance |
125 mm (5″) |
| Seat hight |
710 mm (28″) |
| Vehicle weight |
76 kg (167.2 lb) |
| Dry weight |
72 kg (158.4 lb) |
| Fuel consumption @ 30 km/h (17 mph) |
0.87 l/100 km (260 mi/US gal) |
| Minimum turning radius |
1600mm (63″) |
| Oil capacity |
0.7 liter |
| Fuel tank capacity |
2.8 liter |
