Engine
|
|
| Engine Type |
Air-cooled 4-stroke 2-valve OHC single |
| Displacement |
124.7cc |
| Bore and Stroke |
52.4 x 57.8mm |
| Compression Ratio |
9.2:1 |
| Fuel Delivery |
PGM-FI electronic fuel injection |
| Ignition |
Computer controlled fully transistorised with electronic advance |
| Max. Power Output |
8.3kW/8,000min-1 |
| Max. Torque |
11.2Nm/6,250min-1 |
| Starter |
Electric |
DRIVETRAIN
|
|
| Transmission |
5-speed |
| Final Drive |
2.63 |
| Front Wheel |
U-cross-section 6-spoke cast aluminium 17M/C x MT1.85 |
| Rear Wheel |
U-cross-section 6-spoke cast aluminium 17M/C x MT2.15 |
CHASSIS / SUSPENSION / BRAKES
|
|
| Front Suspension |
30mm telescopic fork, 115mm axle travel |
| Rear Suspension |
Conventional twin shock, double tube damper with 3-step adjustable spring preload, 87mm axle travel |
| Front Brakes |
240mm hydraulic disc with 2-pod caliper and resin mould pads |
| Rear Brakes |
130mm leading/trailing drum |
| Front Tire |
80/100-17M/C (46P) |
| Rear Tire |
100/90-17M/C (55P) |
DIMENSION
|
|
| Seat Height |
792mm (31.2 inches) |
| Wheelbase |
1270mm (50 inches) |
| Curb Weight |
128 kg (282 lb) |
| Fuel Capacity |
13 Litres (3.4 GalUS) |
| Ground Clearance |
173mm (6.8 inches) |
| Overall Length |
1955mm (77 inches) |
| Overall Width |
760mm (30 inches) |
| Overall Height |
1110mm (43.7 inches) |
| Rear |
81 kg (178 lb) |
OTHER
|
|
