2022 Harley Davidson Fat Boy 114 [Specs, Features, Photos]

2022 Harley Davidson Fat Boy 114

The 2022 Harley Davidson Fat Boy 114: The Icon Shines

Largely unchanged, the iconic Fat Boy remains a staple of the 2022 Harley Davidson lineup. The Fat Boy 114 is proof that chrome will always have a place on a motorcycle. From the headlight nacelle and fork tubes, back over the tank console then the engine and exhaust, everywhere this Harley Davidson has chromed elements.

The iconic steamroller stance of the Fat Boy begins with the solid disc Lakester wheels wrapped in fat rubber, 160mm up front and 240mm out back. Such massive rubber is needed in order to harness the power from the Milwaukee-Eight® 114 engine and its 119 lbs-ft of torque, perfect for any power-craving enthusiast of this American company.

3 Color choices for the 2022 Harley Davidson Fat Boy 114: Vivid Black, Reef Blue, and Midnight Crimson/Vivid Black.

The 2022 Harley Davidson Fat Boy 114 starts at $19,530 USD / $24,999 CAD.

On this page: we’ve curated specs, features, news, photos/videos, etc. so you can read up on the new 2022 Harley Davidson Fat Boy 114 in one place.

2022 Harley Davidson Fat Boy 114


Model Overview

General Info

  • Price: $19,999 USD / $24,799 CAD
  • Key Features:
    • Milwaukee-Eight® 114 V-Twin engine
    • Solid Disc Lakester Wheels
    • Forward Controls
    • 160mm Front Tire, 240mm Rear Tire

Main Specs

  • Engine: 1,868cc V-twin
  • Power: 100.5 HP (estimated)
  • Torque: 119 lbs-ft @ 3000 RPM
  • Wet Weight: 699 lbs (317 kg)
  • Seat Height: 25.9 inches (675 mm)

2022 Harley Davidson Fat Boy 114


2022 Harley Davidson Fat Boy 114 Specifications

From Harley-Davidson

ENGINE

Engine 1,868cc V-twin, Milwaukee-Eight® 114
Engine Torque 100.5 HP (estimated)
Bore x Stroke 4.016 in. x 4.5 in.
Compression Ratio
10.5:1
Fuel System Electronic Sequential Port Fuel Injection (ESPFI)
Starter Electric
Exhaust 2-into-2 staggered; catalyst in muffler

DRIVETRAIN

Clutch
Transmission 6-speed
Primary Drive
Gear, 34/46 ratio

CHASSIS

Front Fork
Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring; “beer can” covers
Rear Fork
Hidden, free piston, coil-over monoshock; 43mm stroke; toolless hydraulic preload adjustment
Wheels, Front Type
Machined, Lakester cast aluminum
Wheels, Rear Type
Machined, Lakester cast aluminum
Brakes Front
4-piston fixed front
Brakes Rear 2-piston floating rear
Tires Front
160/60R18,70V,BW
Tires Rear
240/40R18,79V,BW
Fuel Tank Capacity 5 gal.
Color Midnight Crimson/Vivid black, Reef Blue, Vivid black

ELECTRICAL

Ignition
Spark Plugs
Headlight All LED headlamp
Tail Light LED

DIMENSIONS

Length
93.3 in.
Trail
4.1 in.
Rake 30
Wheelbase
65.6 in.
Ground Clearance
4.5 in.
Seat Height
25.9 in.
Weight, As Shipped
671 lb.

WARRANTY

Warranty
Extension

2022 Harley Davidson Fat Boy 114


2022 Harley Davidson Fat Boy 114 Features

MILWAUKEE-EIGHT® BIG TWIN ENGINE

A powerful, smooth-running engine with crisp throttle response and a pure, soul-satisfying rumble.

BRIGHT CHROME FINISHES

An all-you-can eat portion of sculpted bright chrome gives the Fat Boy® motorcycle a look that’ll make a big impact.

STEAMROLLER STANCE

A muscular look thanks to solid-disc Lakester wheels wrapped in the widest front tire we’ve ever offered from the factory at 160mm combined with a rear tire at 240mm.

SIGNATURE LED FORWARD LIGHTING

Darkness-defying lighting that gives you great visibility at night.

HIGH PERFORMANCE FRONT SUSPENSION

Sophisticated suspension technology provides the performance of a racing-style cartridge fork for reduced weight with linear damping characteristics.

HIGH PERFORMANCE REAR MONO SHOCK

Easily adjustable mono-shock rear suspension allows for dynamic cornering while preserving the hardtail look.
